Solar Road Stud Prices of NOKIN Product

2022-04-26

0 views times

Share us:

The cells used in solar road stud are divided into single crystal cells and polycrystalline cells. What are the differences between single crystal cells and polycrystalline cells in solar road studs? The author is happy to answer your doubts about solar road stud.

From the appearance, the solar road stud uses a single crystal cell: the single crystal cell is blackened. The solar road stud uses polycrystalline cells: the polycrystalline cell panel is blue. In terms of light effect, the strong light effect of solar road stud using single crystal cell panel is better, while the weak light effect of solar road stud using polycrystalline cell panel is better.

In terms of conversion efficiency, the conversion efficiency of solar road stud using single crystal cell panel is higher than that of polycrystalline cell panel, and the conversion efficiency of solar road stud using single crystal cell is 17% – 18%. The conversion efficiency of solar road stud using polycrystalline cells is 16% – 17%.

To sum up, if you choose different panels, the price of the whole set of solar road stud is also different. However, at present, polysilicon panels are mostly used in the application of solar road studs.

Because polycrystalline silicon panels are enough to be used in solar road stud power generation system, it is not necessary to use monocrystalline silicon panels. At the same time, due to the serious haze in China, it is a good choice to purchase polycrystalline silicon panels with good weak light effect as the light source of solar road stud.

info@nk-roadstud.com

+86-13602600950

Previous: Solar Road Stud Cell Classification

Next: What Should You Know to Produce Solar Road Stud?

Inquiry

If you have any question or comment, please contact us without hesitation. We will reply you as soon as possible.( * is required information)

*Name:; *Email:; Phone:; Company:; Country:; *Message:

Hot Products

NOKIN Amber Raised Solar Road Stud Light For Expressway NK-RS-A6-1

2020-05-18

Body material: Aluminum(GB-ADC12)+PC(Japan Brand)
Power supply: USA Brand High Efficient Solar Panel
Battery: NI-MH1.2V/600MAH; Lithium battery3.2V/500MAH(Made in Japan);
Resistance: >30T
LED Color: White, Yellow, Blue, Red, Green
Size: L125mm*W107mm*H26+50mm

Heavy Duty Solar Road Stud For Sale NK-RS-X5

2020-05-18

Body material: Casting Aluminium alloy +PC
Power supply: 5V/80MAH Mono crystalline silicon
Battery: Lithium battery3.2V/1000MAH
Resistance: >40T(can be installed in the middle of road)
LED Color: White, Yellow, Blue, Red, Green
Size: φ125*50mm

Round PC Solar Road Stud Light NK-RS-K1

2020-05-18

Body material: PC
Power supply: Solar panel(Monocrystalline 2.5V /0.2W)
Battery: NIMH 600MAH
Resistance: >20T(static)
LED Color: White, Yellow, Blue, Red, Green
Size: φ117*23mm

Ultra Thin PC Solar Road Stud Light For Road NK-RS-Q7

2020-05-18

Body material: PC
Power supply: High efficient solar panel(5V/60mA)
Battery: Lithium battery(3.2V/500mAh)
Resistance: 15T
LED Color: White, Yellow, Blue, Red, Green
Size: 114*90*11mm

Nokin Solar Road Stud For Sale NK-RS-D1

2020-05-18

Body material: Hi-pressure Casting Aluminium alloy
Power supply: Solar panel(monocrystalline 2.5V/0.2W)
Battery: NI-MH 1.2V/800MAH or lithium battery
Resistance: >20T(static)
LED Color: White, Yellow, Blue, Red, Green
Size: L104*W104*H20mm

Yellow Flashing Aluminum Raised Solar Cat Eyes Road Stud On Road NK-RS-A6

2020-05-18

Body material: Hi-pressure Casting Aluminium alloy
Power supply: Solar panel(Monocrystalline 2.5V /0.2W)
Battery: NI-MH1.2V/800MAH
Resistance: >20 Tons
LED Color: White, Yellow, Blue, Red, Green
Size: L123*W133*H22mm+55mm

Internally Illuminated Solar Pavement Levelled Markers Studs NK-RS-X6

2020-05-18

Body material: Aluminum Alloy+PC cover
Power supply: Solar panel(Monocrystalline 2.5V /120MA)
Battery: Lithium battery 1000MAH*3.2V
Resistance: >30 Tons
LED Color: White, Yellow, Blue, Red, Green
Size: Ф123*45mm

6 LED Embedded Solar Road Marker Light Supplier In China NK-RS-A10

2020-05-18

Body material: Cast Aluminum
Power supply: Solar panel(Monocrystalline 2.5V /0.2W)
Battery: NI-MH 1.2V/800MAH
Resistance: >30 Tons
LED Color: White, Yellow, Blue, Red, Green
Size: Ф120*50mm（bottom）
Ф135*50mm（upper）

Colorful Aluminum Solar Road Stud Light For Road NK-RS-A6-2

2020-05-18

Body material: Heavy duty casting aluminium
Power supply: Solar panel(monocrystalline 2.5V/0.2W)
Battery: NI-MH 1.2V/800MAH
Resistance: >20T(static)
LED Color: White, Yellow, Blue, Red, Green
Size: L129*W114*H23mm+53mm

China Aluminuim Solar Road Stud Light For Sale With Best Price NK-RS-T1

2020-05-18

Body material: Aluminum+PC
Power supply: Mono crystalline solar panel
Battery: NI-MH 1.2V/ 600mah(high temperature resistance);
Resistance: >20T(static)
LED Color: White, Yellow, Blue, Red, Green
Size: 125*43*30mm

Colorful Glass Solar Road Stud Cheap Price in China NK-RS-A7

2020-05-18

Body material: Tempered Glass/PC
Power supply: USA Brand High Efficient Solar Panel
Solar panel(Monocrystalline 2.5V /0.2W)
Battery: NI-MH1.2V/600MAH(high temperature resistance, made in China)
Lithum battery3.2V/500MAH(made in Japan)
Resistance: >20T
LED Color: White, Yellow, Blue, Red, Green
Size: φ112*56mm

Aluminium Solar Powered Road Studs For Sale NK-RS-A1

2020-05-15

Body material: Hi-pressure Casting Aluminium alloy
Power supply: Solar panel(monocrystalline 2.5V/0.2W)
Battery: NI-MH 1.2V/800MAH
Resistance: >20T(static)
LED Color: White, Yellow, Blue, Red, Green
Size: L104mm*W94mm*H20mm
